| Artikelnummer | VVX07F015M00 |
| varumärke | Panasonic |
| Storlek | 7.0 |
| Ansökan | PAD |
| Upplösning | 1200×1920 |
| Sammansättning | LCM |
| Ljusstyrka | 450 |
| CR | 1200:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | MIPI |
| panelmärke | Panasonic |
| panelmodell | VVX07F015M00 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 7.0 inch |
| upplösning | 1200(RGB)×1920 , WUXGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| skissera | 104.52×161.87×2.4 mm |
| yta | Hard coating |
| ljusstyrka | 450 cd/m² (Typ.) |
| Kontrastförhållande | 1200:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 30 (Max.)(Tr+Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4S6PWLEDWithout Driver |
| signalgränssnitt | MIPI (4 data lanes), 40 pins |
| inspänning | 1.8/3.7V (Typ.)(VCC/VDD) |
| Ansökan | PAD |
