| Artikelnummer | VVX10F004B00 |
| varumärke | Panasonic |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 600 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | MIPI |
| panelmärke | Panasonic |
| panelmodell | VVX10F004B00 1 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.1 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 217.44×135.9 mm |
| skissera | 228.86×152.5×4.48 mm |
| yta | Hard coating, Antireflection |
| ljusstyrka | 600 cd/m² (Min.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193150% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 10S6PWLEDEmbedded (LED Driver) |
| signalgränssnitt | MIPI (4 data lanes), 45 pins |
| inspänning | 2.5/3.3V (Typ.)(IOVDD/VDD) |
| Ansökan | PAD |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| HJ101NA-02A | Innolux | 10.1 | 1280×800 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| HV121WX5-121 | HYDIS | 12.1 | 1280×800 |
| LD070WX4-SM01 | LG Display | 7.0 | 800×1280 |
| LP079X01-SMA7 | LG Display | 7.9 | 768×1024 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LTL097QL01-W01 | Samsung | 9.7 | 2048×1536 |
| LTL120QL01-001 | Samsung | 12.0 | 2160×1440 |
