| Artikelnummer | HE101NA-02C |
| varumärke | Innolux |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1280×800 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 700:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | TTL |
| panelmärke | CHIMEI INNOLUX |
| panelmodell | HE101NA-02C |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 10.1 inch |
| upplösning | 1280(RGB)×800 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 216.96×135.6 mm |
| skissera | 224.21×145×1.43 mm |
| yta | Glare (Haze 0%) |
| glasdjup | 0.50+0.50 mm |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 10/20 (Typ.)(Tr/Td) |
| betraktningsvinkel | 75/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | Parallel RGB (1 ch, 8-bit), 40 pins |
| inspänning | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Ansökan | PAD |
