| Artikelnummer | TX31D37VM0CAA |
| varumärke | KOE |
| Storlek | 12.1 |
| Ansökan | IA |
| Upplösning | 800×600 |
| Sammansättning | LCM |
| Ljusstyrka | 600 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | HITACHI |
| panelmodell | TX31D37VM0CAA |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 800(RGB)×600 , SVGA |
| visningsläge | IPS Pro, Normally Black, Transmissive |
| aktivt område | 246×184.5 mm |
| skissera | 280×210×13.08 mm |
| yta | |
| ljusstyrka | 600 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 3S8PWLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
