| Artikelnummer | TX31D32VM2AAA |
| varumärke | KOE |
| Storlek | 12.1 |
| Ansökan | IA |
| Upplösning | 800×600 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 500:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | HITACHI |
| panelmodell | TX31D32VM2AAA |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 800(RGB)×600 , SVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| skissera | 280×210×13.5 mm |
| yta | Hard coating (3H) |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 15/10 (Typ.)(Tr/Td) |
| betraktningsvinkel | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 2 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
