| Artikelnummer | DLC1210BBG-2 |
| varumärke | Other |
| Storlek | 12.1 |
| Ansökan | IA |
| Upplösning | 800×600 |
| Sammansättning | LCM |
| Ljusstyrka | 1000 |
| CR | 800:1 |
| Färger | 262K/16.2M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | DLC |
| panelmodell | DLC1210BBG-2 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 800(RGB)×600 , SVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| skissera | 279×209×9.3 mm |
| yta | |
| ljusstyrka | 1000 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/65/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6/8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
