| Artikelnummer | HV121X02-100 |
| varumärke | HYDIS |
| Storlek | 12.1 |
| Ansökan | IA |
| Upplösning | 1024×768 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 450:1 |
| Färger | 262K |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | LVDS |
| panelmärke | BOE HYDIS |
| panelmodell | HV121X02-100 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 12.1 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | AFFS, Normally Black, Transmissive |
| aktivt område | 245.76×184.32 mm |
| yta | Glare (Haze 0%), Antireflection |
| transmissivitet | 5.91% (Typ.)(with Polarizer) |
| Kontrastförhållande | 450:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193140% |
| respons tid | 32 (Typ.)(Tr+Td) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | LVDS (1 ch, 6-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
