| Artikelnummer | DLC1210EIG |
| varumärke | Other |
| Storlek | 12.1 |
| Ansökan | CNS |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 600 |
| CR | 600:1 |
| Färger | 262K/16.2M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | DLC |
| panelmodell | DLC1210EIG |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| skissera | 260.5×204×8.9 mm |
| yta | |
| ljusstyrka | 600 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K/16.2M (6-bit / 6-bit + FRC), CIE193163% |
| respons tid | 5/11 (Typ.)(Tr/Td) |
| betraktningsvinkel | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 6/8-bit), 20 pins |
| inspänning | 3.3/5.0V (Typ.)(VCC) |
| Ansökan | CNS |
| B121EW03 V0 | AUO | 12.1 | 1280×800 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| DLC1210BBG-2 | Other | 12.1 | 800×600 |
| DLC1210EIG | Other | 12.1 | 1024×768 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| LP121X05-A2 | LG Display | 12.1 | 1024×768 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| LTD121EXED | TOSHIBA | 12.1 | 1280×800 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| N121IB-L05 Rev.C1 | Innolux | 12.1 | 1280×800 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| C065VL01 V0 | AUO | 6.5 | 800×480 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| PD040QT2 | E Ink | 4.0 | 320×240 |
| PM070WU1 | E Ink | 7.0 | 800×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
