| Artikelnummer | TX38D88VC1GAA |
| varumärke | KOE |
| Storlek | 15.0 |
| Ansökan | NBPC |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 430 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | HITACHI |
| panelmodell | TX38D88VC1GAA |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.0 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| skissera | 315.8×241.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Glare (Haze 0%) |
| ljusstyrka | 430 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit) |
| respons tid | 30/20 (Typ.)(Tr/Td) |
| betraktningsvinkel | 80/80/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 2 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| HV150UX1-101 | HYDIS | 15.0 | 1600×1200 |
| LP150E07-TL02 | LG Display | 15.0 | 1400×1050 |
| LQ150X1DWF1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LX95 | SHARP | 15.0 | 1024×768 |
| LTN150P4-L01 | Samsung | 15.0 | 1400×1050 |
| N150P2-L04 | IDTech | 15.0 | 1400×1050 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-24D | NLT | 15.0 | 1024×768 |
| T150XG01 V0 | AUO | 15.0 | 1024×768 |
| TX38D88VC1GAA | KOE | 15.0 | 1024×768 |
| B140XTN01.3 | AUO | 14.0 | 1366×768 |
| B156HW02 V1 | AUO | 15.6 | 1920×1080 |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| LP133WH2-SPA1 | LG Display | 13.3 | 1366×768 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| LP171WP9-TLB3 | LG Display | 17.1 | 1440×900 |
| LTN160AT04-N01 | Samsung | 16.0 | 1366×768 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| N173HGE-L11 | Innolux | 17.3 | 1920×1080 |
| UB141X01 | UNIPAC | 14.1 | 1024×768 |
