| Artikelnummer | TM084SDHG02 |
| varumärke | Tianma |
| Storlek | 8.4 |
| Ansökan | IA |
| Upplösning | 800×600 |
| Sammansättning | LCM |
| Ljusstyrka | 330 |
| CR | 500:1 |
| Färger | 262K/16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | TIANMA |
| panelmodell | TM084SDHG02 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 8.4 inch |
| upplösning | 800(RGB)×600 , SVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 170.4×127.8 mm |
| skissera | 189.75×149.4 mm |
| yta | Antiglare |
| ljusstyrka | 330 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| respons tid | 20 (Typ.)(Tr+Td) |
| betraktningsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 3S7PWLEDWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 6/8-bit), 60 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
