| Artikelnummer | NL10276BC30-39 |
| varumärke | NLT |
| Storlek | 15.0 |
| Ansökan | IA |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 270 |
| CR | 900:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | NEC |
| panelmodell | NL10276BC30-39 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.0 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | UA-SFT, Normally Black, Transmissive |
| aktivt område | 304.128×228.096 mm |
| skissera | 326.5×253.5×12.2 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 270 cd/m² (Typ.) |
| Kontrastförhållande | 900:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 14/11 (Typ.)(Tr/Td) |
| betraktningsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 6 stringsWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
