| Artikelnummer | NL10276BC28-21A |
| varumärke | NLT |
| Storlek | 14.1 |
| Ansökan | NBPC |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 150 |
| CR | 150:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | NEC |
| panelmodell | NL10276BC28-21A |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 14.1 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 285.696×214.272 mm |
| skissera | 298×225.5×5.7 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Hard coating (3H) |
| ljusstyrka | 150 cd/m² (Typ.) |
| Kontrastförhållande | 150:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193140% |
| respons tid | 15/50 (Typ.)(Tr/Td) |
| betraktningsvinkel | 50/50/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 1 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
