| Artikelnummer | LTN121AP06-301 |
| varumärke | Samsung |
| Storlek | 12.1 |
| Ansökan | PAD |
| Upplösning | 1280×800 |
| Sammansättning | LCM |
| Ljusstyrka | |
| CR | |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTN121AP06-301 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 1280(RGB)×800 , WXGA |
| visningsläge | PVA, Normally Black, Transmissive |
| aktivt område | 261.12×163.2 mm |
| yta | |
| ljusstyrka | |
| Kontrastförhållande | |
| visa färger | 262K (6-bit) |
| respons tid | |
| betraktningsvinkel | |
| frekvens | 60Hz |
| lamptyp | WLED |
| signalgränssnitt | LVDS (1 ch, 6-bit) |
| Ansökan | PAD |
| LTN121AP03-001 | Samsung | 12.1 | 1280×800 |
| LTN121AP03-002 | Samsung | 12.1 | 1280×800 |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| LTN121AT02-001 | Samsung | 12.1 | 1280×800 |
| LTN121AT04-001 | Samsung | 12.1 | 1280×800 |
| LTN121AT07-L02 | Samsung | 12.1 | 1280×800 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121AT11-801 | Samsung | 12.1 | 1280×800 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| HSD100PXN1-A00-C40 | HannStar | 10.0 | 1024×768 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| LTL106AL01-002 | Samsung | 10.6 | 1366×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
