| Artikelnummer | HT10X21-311 |
| varumärke | HYDIS |
| Storlek | 10.4 |
| Ansökan | PAD |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 170 |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | BOE HYDIS |
| panelmodell | HT10X21-311 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.4 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | FFS, Normally Black, Transmissive |
| aktivt område | 210.4×157.8 mm |
| skissera | 238.6×173.2 mm |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| ljusstyrka | 170 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 40 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 1 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 14 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| G104V1-T01 | Innolux | 10.4 | 640×480 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| LTD104KA1S | TOSHIBA | 10.4 | 1024×768 |
| LTD121EDKP | TOSHIBA | 10.4 | 1024×768 |
| LTM10C209H | TOSHIBA | 10.4 | 640×480 |
| PD104VT3 | E Ink | 10.4 | 640×480 |
| TX26D14VM2EAA | KOE | 10.4 | 640×480 |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LT101MB02000 | JDI | 10.1 | 1920×1200 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| VVX07H005A00 | Panasonic | 7.0 | 800×1280 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
