| Artikelnummer | HSD190MGW1-B00 |
| varumärke | HannStar |
| Storlek | 19.0 |
| Ansökan | DMPC |
| Upplösning | 1440×900 |
| Sammansättning | LCM |
| Ljusstyrka | 350 |
| CR | 700:1 |
| Färger | 16.2M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | HannStar |
| panelmodell | HSD190MGW1-B00 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 19.0 inch |
| upplösning | 1440(RGB)×900 , WXGA+ |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 408.24×255.15 mm |
| skissera | 428×278×19 mm |
| yta | Glare (Haze 0%), Hard coating (3H) |
| ljusstyrka | 350 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 16.2M (6-bit + FRC), CIE193172% |
| respons tid | 1.5/3.5 (Typ.)(Tr/Td) |
| betraktningsvinkel | 75/75/75/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-A13 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MGW1-B00 | HannStar | 19.0 | 1440×900 |
| LM200WD3-TLC9 | LG Display | 20.0 | 1600×900 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| LTM340YP02 | Samsung | 34 | 3440×1440 |
| M150EW01 V0 | AUO | 15.0 | 1280×720 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
