| Artikelnummer | HSD190ME13-A13 |
| varumärke | HannStar |
| Storlek | 19.0 |
| Ansökan | DMPC |
| Upplösning | 1280×1024 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 700:1 |
| Färger | 16.2M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | HannStar |
| panelmodell | HSD190ME13-A13 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 19.0 inch |
| upplösning | 1280(RGB)×1024 , SXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 376.32×301.056 mm |
| skissera | 396×324×18 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 16.2M (6-bit + FRC) |
| respons tid | 2/6 (Typ.)(Tr/Td) |
| betraktningsvinkel | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-A13 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN4-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM220WE4-SLB1 | LG Display | 22.0 | 1680×1050 |
| LM270WQ1-SDC2 | LG Display | 27.0 | 2560×1440 |
| LQ150X1DWF1 | SHARP | 15.0 | 1024×768 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
