| Artikelnummer | HSD190ME13-D10 |
| varumärke | HannStar |
| Storlek | 19.0 |
| Ansökan | DMPC |
| Upplösning | 1280×1024 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 700:1 |
| Färger | 16.2M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | HannStar |
| panelmodell | HSD190ME13-D10 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 19.0 inch |
| upplösning | 1280(RGB)×1024 , SXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 376.32×301.056 mm |
| skissera | 396×324×18 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 16.2M (6-bit + FRC) |
| respons tid | 1.5/3.5 (Typ.)(Tr/Td) |
| betraktningsvinkel | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
