| Artikelnummer | HSD101PUW1-A00 |
| varumärke | HannStar |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 380 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | MIPI |
| panelmärke | HannStar |
| panelmodell | HSD101PUW1-A00 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.1 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | HS-IPS, Normally Black, Transmissive |
| aktivt område | 216.576×135.36 mm |
| skissera | 227.72×147.8×4.55 mm |
| yta | Hard coating |
| ljusstyrka | 380 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193150% |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | MIPI (4 data lanes), 34 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
