| Artikelnummer | LTL106HL01-001 |
| varumärke | Samsung |
| Storlek | 10.6 |
| Ansökan | PAD |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTL106HL01-001 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.6 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | PLS, Normally Black, Transmissive |
| aktivt område | 234.72×132.03 mm |
| skissera | 246.52×149.02×5.2 mm |
| yta | Glare (Haze 0%), Hard coating (2H) |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193150% |
| respons tid | 16 (Typ.)(Tr+Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 9S4PWLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 8-bit), 51 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
