| Artikelnummer | WEO012864DR |
| varumärke | Winstar |
| Storlek | 0.96 |
| Ansökan | Handheld & PDA H |
| Upplösning | 128×64 |
| Sammansättning | PM-OLED, OLED |
| Ljusstyrka | |
| CR | |
| Färger | Mono(Red) |
| Bakgrundsbelysning | self |
| Gränssnitt | 8-bit |
| panelmärke | Winstar |
| panelmodell | WEO012864DR |
| panelstorlek | 0.96" |
| paneltyp | PM-OLED, OLED |
| upplösning | 128×64, 149PPI |
| pixelformat | Rectangle |
| visningsområde | 21.738(W)×10.858(H) mm |
| ramöppning | 23.938(W)×12.058(H) mm |
| konturstorlek | 26.7(W)×19.26(H) ×1.81(D) mm |
| yta | - |
| betraktningsvinkel | - |
| visningsläge | - |
| bästa utsikten på | Symmetry |
| respons tid | - |
| visa färger | Mono(Red) |
| lamptyp | self |
| frekvens | - |
| pekskärm | Without |
| drivrutin ic | COG Built-in SSD1306BZ |
| panelvikt | - |
| Ansökan | Handheld & PDA Healthcare Instruments & Meters |
| signalgränssnitt | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| inspänning | 3.0V (Typ.) |
