| Artikelnummer | OEL9M0083-R-E |
| varumärke | Other |
| Storlek | 0.96 |
| Ansökan | |
| Upplösning | 128×64 |
| Sammansättning | OLED |
| Ljusstyrka | |
| CR | 10000:1 |
| Färger | Mono(Red) |
| Bakgrundsbelysning | self |
| Gränssnitt | CPU/SPI/I²C |
| panelmärke | TRULY |
| panelmodell | OEL9M0083-R-E |
| paneltyp | PM-OLED , OLED |
| panelstorlek | 0.96 inch |
| upplösning | 128×64 |
| aktivt område | 21.74×11.175 mm |
| skissera | 26.7×19.26×1.65 mm |
| yta | |
| ljusstyrka | |
| Kontrastförhållande | 10000 : 1 (Min.) |
| visa färger | Mono(Red) (1-bit) |
| betraktningsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvens | 100Hz |
| drivrutin ic | COG Built-in SH1106G |
| signalgränssnitt | 8-bit 6800/8080 parallel, 3/4-wire SPI, I²C, 30 pins |
