| Artikelnummer | V315B5-LE3 |
| varumärke | Innolux |
| Storlek | 31.5 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 5000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | CHIMEI INNOLUX |
| panelmodell | V315B5-LE3 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 31.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | Super MVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| skissera | 735.4×433 mm |
| yta | Antiglare (Haze 11%), Hard coating (3H) |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 5000:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 8.5 (Typ.)(Tr+Td) |
| betraktningsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
| V315B1-L01 | Innolux | 31.5 | 1366×768 |
| V315B3-L04 | Innolux | 31.5 | 1366×768 |
| V315B5-L01 | Innolux | 31.5 | 1366×768 |
| V315B5-L02 | Innolux | 31.5 | 1366×768 |
| V315B5-L03 | Innolux | 31.5 | 1366×768 |
| V315B5-L06 | Innolux | 31.5 | 1366×768 |
| V315B5-LE3 | Innolux | 31.5 | 1366×768 |
| V315B6-L02 | Innolux | 31.5 | 1366×768 |
| V315B6-L03 | Innolux | 31.5 | 1366×768 |
| V315B6-L04 | Innolux | 31.5 | 1366×768 |
| LC150X01-SL01 | LG Display | 15.0 | 1024×768 |
| LC370EUN-SDV1 | LG Display | 37 | 1920×1080 |
| LC550EQE-PGF2 | LG Display | 55 | 3840×2160 |
| LC550EUF-PGF1 | LG Display | 55 | 1920×1080 |
| LTA230AN01 | Samsung | 23.0 | 1366×768 |
| LTA460HB08 | Samsung | 46 | 1920×1080 |
| T420HVN05.2 | AUO | 42 | 1920×1080 |
| T460HW03 VB | AUO | 46 | 1920×1080 |
| V420H2-LE3 | Innolux | 42 | 1920×1080 |
| V650HP1-LS6 Rev.E | Innolux | 65 | 1920×1080 |
