| Artikelnummer | LTA230AN01 |
| varumärke | Samsung |
| Storlek | 23.0 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 250 |
| CR | 4000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTA230AN01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 23.0 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | PVA, Normally Black, Transmissive |
| aktivt område | 508.152×285.696 mm |
| skissera | 534×311.8×11 mm |
| yta | Antiglare (Haze 2.3%) |
| ljusstyrka | 250 cd/m² (Typ.) |
| Kontrastförhållande | 4000:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193168% |
| respons tid | 8 (Typ.)(G to G) |
| betraktningsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 10S3PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
