| Artikelnummer | T420HW07 V4 |
| varumärke | AUO |
| Storlek | 42 |
| Ansökan | LCTV |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 450 |
| CR | 4000:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | AUO |
| panelmodell | T420HW07 V4 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 42 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | AMVA3, Normally Black, Transmissive |
| aktivt område | 930.24×523.26 mm |
| skissera | 973.2×566.2×23.9 mm |
| yta | Antiglare (Haze 13%), Hard coating (3H) |
| ljusstyrka | 450 cd/m² (Typ.) |
| Kontrastförhållande | 4000:1 (Typ.) |
| visa färger | 1.07B (8-bit + Hi-FRC), CIE193172% |
| respons tid | 6.5 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (4 ch, 10-bit), 92 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
