| Artikelnummer | S50HW-YB06 |
| varumärke | Samsung |
| Storlek | 50 |
| Ansökan | LCTV |
| Upplösning | 1365×768 |
| Sammansättning | PDP |
| Ljusstyrka | 630 |
| CR | 5000:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | self |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG SDI |
| panelmodell | S50HW-YB06 |
| paneltyp | PDP , PDP |
| panelstorlek | 50 inch |
| upplösning | 1365(RGB)×768 , WXGA |
| aktivt område | 1105.65×622.08 mm |
| skissera | 1175.4×688 mm |
| yta | |
| ljusstyrka | 630 cd/m² (Typ.) |
| Kontrastförhållande | 5000 : 1 (Typ.) |
| visa färger | 1.07B (10-bit) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| Ansökan | LCTV |
