| Artikelnummer | T230XW01 V2 |
| varumärke | AUO |
| Storlek | 23.0 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 500 |
| CR | 450:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | AUO |
| panelmodell | T230XW01 V2 1 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 23.0 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 508.152×285.696 mm |
| skissera | 546×318.3 mm |
| yta | Antiglare (Haze 26%), Hard coating (3H) |
| ljusstyrka | 500 cd/m² (Typ.) |
| Kontrastförhållande | 450:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 6/10 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 8 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
