| Artikelnummer | V500HJ1-ME1 |
| varumärke | Innolux |
| Storlek | 50 |
| Ansökan | LCTV |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 5000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | CHIMEI INNOLUX |
| panelmodell | V500HJ1-ME1 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 50 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | Super MVA, Normally Black, Transmissive |
| aktivt område | 1095.84×616.41 mm |
| skissera | 1121.6×644.1×33.2 mm |
| yta | Antiglare (Haze 1%), Hard coating (3H) |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 5000:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 9.5 (Typ.)(G to G) |
| betraktningsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDWithout Driver |
| signalgränssnitt | LVDS (2 ch, 8-bit), 51 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
