| Artikelnummer | NL192108AC10-01D |
| varumärke | NLT |
| Storlek | 9.0 |
| Ansökan | IA |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 700:1 |
| Färger | 262K/16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | NLT |
| panelmodell | NL192108AC10-01D |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 9.0 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | UA-SFT, Normally Black, Transmissive |
| aktivt område | 198.72×111.78 mm |
| skissera | 214.6×130×9.6 mm |
| yta | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| respons tid | 13/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 6/8-bit), 50 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
