| Artikelnummer | NL12876BC15-01 |
| varumärke | NLT |
| Storlek | 8.9 |
| Ansökan | NBPC |
| Upplösning | 1280×768 |
| Sammansättning | LCM |
| Ljusstyrka | 280 |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | NEC |
| panelmodell | NL12876BC15-01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 8.9 inch |
| upplösning | 1280(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 193.92×116.352 mm |
| skissera | 209.2×130.3×7.7 mm |
| yta | Clear, Hard coating (3H) |
| ljusstyrka | 280 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193156% |
| respons tid | 6/2 (Typ.)(Tr/Td) |
| betraktningsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 11S3PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
