| Artikelnummer | LP171WP6-TL04 |
| varumärke | LG Display |
| Storlek | 17.1 |
| Ansökan | NBPC |
| Upplösning | 1440×900 |
| Sammansättning | LCM |
| Ljusstyrka | 450 |
| CR | 700:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | LG.Philips LCD |
| panelmodell | LP171WP6-TL04 1 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 17.1 inch |
| upplösning | 1440(RGB)×900 , WXGA+ |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| skissera | 382.2×246.8×10 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Glare (Haze 0%), Hard coating (2H), Antireflection |
| ljusstyrka | 450 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 262K (6-bit) |
| respons tid | 4/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 2 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
