| Artikelnummer | M125NWN1 R0 |
| varumärke | IVO |
| Storlek | 12.5 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 200 |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | eDP |
| panelmärke | IVO |
| panelmodell | M125NWN1 R0 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 276.615×155.52 mm |
| skissera | 290.5×181.4×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 200 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 3/5 (Typ.)(Tr/Td) |
| betraktningsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | eDP (2 Lanes), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.2 | AUO | 12.5 | 1920×1080 |
| HB125WX1-100 | BOE | 12.5 | 1366×768 |
| LP125WF2-SPB2 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LTN125AT02-301 | Samsung | 12.5 | 1366×768 |
| M125NWN1 R0 | IVO | 12.5 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| B141XN04 V2 | AUO | 14.1 | 1024×768 |
| HB140FH1-301 | BOE | 14.0 | 1920×1080 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP156WHU-TPD1 | LG Display | 15.6 | 1366×768 |
| LTD121KX4K | TOSHIBA | 12.1 | 1280×800 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN154X1-L01 | Samsung | 15.4 | 1280×800 |
| LTN156FL01-D01 | Samsung | 15.6 | 3840×2160 |
| N154I2-L05 | Innolux | 15.4 | 1280×800 |
