| Artikelnummer | B125HAN02.2 |
| varumärke | AUO |
| Storlek | 12.5 |
| Ansökan | NBPC |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 700:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | eDP |
| panelmärke | AUO |
| panelmodell | B125HAN02.2 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.5 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | AHVA, Normally Black, Transmissive |
| aktivt område | 276.48×155.52 mm |
| skissera | 282.4×179.32×2.5 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| yta | Antiglare |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 700:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193150% |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | eDP (2 Lanes), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
