| Artikelnummer | LTY460JN12 |
| varumärke | Other |
| Storlek | 46 |
| Ansökan | LCTV |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 550 |
| CR | 8000:1 |
| Färger | 1.06B |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | No Brand |
| panelmodell | LTY460JN12 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 46 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | SVA, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| skissera | 1029.9×585.5 mm, Videowall Seam 11.7 mm |
| yta | Hard coating (2H), Reflection 1.4% (Max.) |
| ljusstyrka | 550 cd/m² (Typ.) |
| Kontrastförhållande | 8000:1 (Typ.) |
| visa färger | 1.06B (8-bit + Dithering), CIE193176% |
| respons tid | 3.5 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz (60Hz Input) |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 8-bit), 50 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
