| Artikelnummer | LTY400WS-L02 |
| varumärke | Samsung |
| Storlek | 40 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 530 |
| CR | 1200:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | S-LCD |
| panelmodell | LTY400WS-L02 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 40 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | S-PVA, Normally Black, Transmissive |
| aktivt område | 885.168×497.664 mm |
| skissera | 952×551×52 mm |
| yta | Antiglare (Haze 44%), Hard coating (3H) |
| ljusstyrka | 530 cd/m² (Typ.) |
| Kontrastförhållande | 1200:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 20 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 41 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | LCTV |
