| Artikelnummer | LTP350QV-E06 |
| varumärke | Samsung |
| Storlek | 3.5 |
| Ansökan | |
| Upplösning | 240×320 |
| Sammansättning | LCM |
| Ljusstyrka | 60 |
| CR | 80:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | SAMSUNG |
| panelmodell | LTP350QV-E06 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.5 inch |
| upplösning | 240(RGB)×320 , QVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 53.64×71.52 mm |
| skissera | 64.3×87.1×4.85 mm |
| yta | Hard coating (3H) |
| ljusstyrka | 60 cd/m² (Typ.) |
| Kontrastförhållande | 80:1 (Typ.) |
| visa färger | 262K (6-bit) |
| respons tid | 40 (Typ.)(Tr+Td) |
| betraktningsvinkel | 40/40/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| lamptyp | WLED |
| signalgränssnitt | Parallel RGB (1 ch, 6-bit), 60 pins |
| inspänning | 3.3/5.0V (Typ.)(DVDD/AVDD) |
