| Artikelnummer | LTN140AT20-T01 |
| varumärke | Samsung |
| Storlek | 14.0 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTN140AT20-T01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 14.0 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 309.399×173.952 mm |
| yta | |
| ljusstyrka | |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K (6-bit) |
| respons tid | 16 (Typ.)(Tr+Td) |
| betraktningsvinkel | 45/45/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLED |
| signalgränssnitt | LVDS (1 ch, 6-bit) |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT07-L01 | Samsung | 14.0 | 1366×768 |
| LTN140AT07-T01 | Samsung | 14.0 | 1366×768 |
| LTN140AT07-W01 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-701 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-002 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT26-L01 | Samsung | 14.0 | 1366×768 |
| B140XTN03.9 | AUO | 14.0 | 1366×768 |
| LP133WH2-TLE1 | LG Display | 13.3 | 1366×768 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLR1 | LG Display | 15.6 | 1366×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTN141X8-L00 | Samsung | 14.1 | 1024×768 |
| LTN156AT24-B01 | Samsung | 15.6 | 1366×768 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| N133BGE-E51 | Innolux | 13.3 | 1366×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
