| Artikelnummer | LTN133AT23-B01 |
| varumärke | Samsung |
| Storlek | 13.3 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | |
| CR | 220:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTN133AT23-B01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 13.3 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 293.42×164.97 mm |
| yta | |
| ljusstyrka | |
| Kontrastförhållande | 220:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 16 (Typ.)(Tr+Td) |
| betraktningsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 6-bit) |
| Ansökan | NBPC |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT07-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT09-G02 | Samsung | 13.3 | 1280×800 |
| LTN133AT09-W01 | Samsung | 13.3 | 1280×800 |
| LTN133AT13-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT14-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT16-S01 | Samsung | 13.3 | 1280×800 |
| LTN133AT17-H01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-205 | Samsung | 13.3 | 1366×768 |
| B140RW02 V1 | AUO | 14.0 | 1600×900 |
| B156HW01 V1 | AUO | 15.6 | 1920×1080 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| CLAA140WB11A | CPT | 14.0 | 1366×768 |
| LP140WH2-TLEA | LG Display | 14.0 | 1366×768 |
| LP154WX2-TL01 | LG Display | 15.4 | 1280×800 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LT104V3-100 | Samsung | 10.4 | 640×480 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| N133HSE-EB3 | Innolux | 13.3 | 1920×1080 |
