| Artikelnummer | LTM240CL01 |
| varumärke | Samsung |
| Storlek | 24.0 |
| Ansökan | DMPC |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTM240CL01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 24.0 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | PLS, Normally Black, Transmissive |
| aktivt område | 518.4×324 mm |
| skissera | 546.4×352×15 mm |
| yta | Antiglare (Haze 47%), Hard coating (3H) |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193172% |
| respons tid | 12 (Typ.)(Tr+Td) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 14S4PWLEDWithout Driver |
| signalgränssnitt | LVDS (2 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
