| Artikelnummer | LTM185AT05 |
| varumärke | Samsung |
| Storlek | 18.5 |
| Ansökan | DMPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 250 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTM185AT05 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 18.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 409.8×230.4 mm |
| skissera | 430.37×254.6×1.6 mm |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| ljusstyrka | 250 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193172% |
| respons tid | 5 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 7S3PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
| LTM181E3-P01 | Samsung | 18.1 | 1280×1024 |
| LTM181E4-L01 | Samsung | 18.1 | 1280×1024 |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LQ181E1LW31 | SHARP | 18.1 | 1280×1024 |
| LTM220MT05 | Samsung | 22.0 | 1680×1050 |
| M215HW01 V5 | AUO | 21.5 | 1920×1080 |
| M215HW01 V6 | AUO | 21.5 | 1920×1080 |
| M236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
