| Artikelnummer | LTM150XH-L06 |
| varumärke | Samsung |
| Storlek | 15.0 |
| Ansökan | DMPC |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 400:1 |
| Färger | 16.2M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTM150XH-L06 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.0 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| skissera | 331.6×254.8×13 mm |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 400:1 (Typ.) |
| visa färger | 16.2M (6-bit + FRC) |
| respons tid | 5/20 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | DMPC |
