| Artikelnummer | LTM150XH-L04 |
| varumärke | Samsung |
| Storlek | 15.0 |
| Ansökan | DMPC |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 330 |
| CR | 300:1 |
| Färger | 16.2M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTM150XH-L04 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.0 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| skissera | 331.6×254.8×13 mm |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| ljusstyrka | 330 cd/m² (Typ.) |
| Kontrastförhållande | 300:1 (Typ.) |
| visa färger | 16.2M (6-bit + FRC) |
| respons tid | 5/20 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 4 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | DMPC |
| CLAA150PB03 | CPT | 15.0 | 1400×1050 |
| LTM150XH-L01 | Samsung | 15.0 | 1024×768 |
| LTM150XH-L04 | Samsung | 15.0 | 1024×768 |
| LTM150XH-L06 | Samsung | 15.0 | 1024×768 |
| LTM150XH-T01 | Samsung | 15.0 | 1024×768 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| LTM150XO-L21 | Samsung | 15.0 | 1024×768 |
| LTM150XS-L04 | Samsung | 15.0 | 1024×768 |
| LTM150XS-T01 | Samsung | 15.0 | 1024×768 |
| TM150TCS02 | Tianma | 15.0 | 1024×768 |
| CLAA215FA04 | CPT | 21.5 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| LM150X07-B4 | LG Display | 15.0 | 1024×768 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM250WF1-TLA1 | LG Display | 25.0 | 1920×1080 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| M200FGE-L20 | Innolux | 20.0 | 1600×900 |
| M280HKJ-L30 | Innolux | 28.0 | 1920×1080 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| TMS156WX1-01TB | Tianma | 15.6 | 1366×768 |
