| Artikelnummer | LQ101K1LY02 |
| varumärke | SHARP |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1280×800 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SHARP |
| panelmodell | LQ101K1LY02 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.1 inch |
| upplösning | 1280(RGB)×800 , WXGA |
| visningsläge | ASV, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| skissera | 238.12×156.48×6 mm |
| yta | Glare (Haze 0%), Antireflection |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 7S6PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 40 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
