| Artikelnummer | LQ315T3LZ23 |
| varumärke | SHARP |
| Storlek | 31.5 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 500 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | SHARP |
| panelmodell | LQ315T3LZ23 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 31.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| skissera | 780×450 mm |
| yta | Antiglare (Haze 23%), Hard coating (2H), Antireflection |
| ljusstyrka | 500 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193173% |
| respons tid | 12/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 18 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 37 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | LCTV |
