| Artikelnummer | LQ121S1LG44 |
| varumärke | SHARP |
| Storlek | 12.1 |
| Ansökan | IA |
| Upplösning | 800×600 |
| Sammansättning | LCM |
| Ljusstyrka | 370 |
| CR | 450:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | SHARP |
| panelmodell | LQ121S1LG44 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 12.1 inch |
| upplösning | 800(RGB)×600 , SVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| skissera | 276×209×11 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 370 cd/m² (Typ.) |
| Kontrastförhållande | 450:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193150% |
| respons tid | 15/30 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 2 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 20 pins |
| inspänning | 3.3/5.0V (Typ.) |
| Ansökan | IA |
