| Artikelnummer | LQ104V1DG62 |
| varumärke | SHARP |
| Storlek | 10.4 |
| Ansökan | IA |
| Upplösning | 640×480 |
| Sammansättning | LCM |
| Ljusstyrka | 450 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | SHARP |
| panelmodell | LQ104V1DG62 1 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.4 inch |
| upplösning | 640(RGB)×480 , VGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| skissera | 246.5×179.4×12.5 mm |
| yta | Antiglare, Hard coating (3H), Antireflection |
| ljusstyrka | 450 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193140% |
| respons tid | 10/25 (Typ.)(Tr/Td) |
| betraktningsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 7S3PWLEDWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 6-bit), 31 pins |
| inspänning | 3.3/5.0V (Typ.)(VCC) |
| Ansökan | IA |
