| Artikelnummer | LP171WU1-A4K2 |
| varumärke | LG Display |
| Storlek | 17.1 |
| Ansökan | NBPC |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 180 |
| CR | 350:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | LG.Philips LCD |
| panelmodell | LP171WU1-A4K2 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 17.1 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| skissera | 382.7×267.2×6.6 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Glare (Haze 0%), Hard coating (2H) |
| ljusstyrka | 180 cd/m² (Typ.) |
| Kontrastförhållande | 350:1 (Min.) |
| visa färger | 262K (6-bit), CIE193150% |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 65/65/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 1 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
