| Artikelnummer | LP156WF3-SLB1 |
| varumärke | LG Display |
| Storlek | 15.6 |
| Ansökan | NBPC |
| Upplösning | 1920×1080 |
| Sammansättning | LCM |
| Ljusstyrka | 210 |
| CR | 800:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | RGB LED |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LP156WF3-SLB1 2 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.6 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | S-IPS, Normally Black, Transmissive |
| aktivt område | 344.16×193.59 mm |
| skissera | 359.3×212.1×7.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 210 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 1.07B (10-bit), CIE1931110% |
| respons tid | 30 (Typ.)(Tr+Td); 15 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | RGB LEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 10-bit), 50 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
