| Artikelnummer | LP140WH4-TLB1 |
| varumärke | LG Display |
| Storlek | 14.0 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 220 |
| CR | |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LP140WH4-TLB1 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 14.0 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 309.399×173.952 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | |
| ljusstyrka | 220 cd/m² (Typ.) |
| Kontrastförhållande | |
| visa färger | 262K (6-bit) |
| respons tid | |
| betraktningsvinkel | |
| frekvens | 60Hz |
| lamptyp | WLED |
| signalgränssnitt | LVDS (1 ch, 6-bit) |
| Ansökan | NBPC |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP140WF3-SPD1 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TLA3 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLC1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLE2 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLEA | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLC1 | LG Display | 14.0 | 1366×768 |
| B156XW04 V6 | AUO | 15.6 | 1366×768 |
| HSD160PHW1-B00 | HannStar | 16.0 | 1366×768 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LP154W01-TLAD | LG Display | 15.4 | 1280×800 |
| LP156WF6-SPB1 | LG Display | 15.6 | 1920×1080 |
| LTN141AT09-301 | Samsung | 14.1 | 1280×800 |
| LTN156AT02-W01 | Samsung | 15.6 | 1366×768 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N156BGE-L21 | Innolux | 15.6 | 1366×768 |
