| Artikelnummer | LP101WH4-SLAA |
| varumärke | LG Display |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1366×768 |
| Sammansättning | Assembly |
| Ljusstyrka | 315 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LP101WH4-SLAA |
| paneltyp | a-Si TFT-LCD , Assembly |
| panelstorlek | 10.1 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| aktivt område | 222.52×125.11 mm |
| skissera | 254.3×158×5.45 mm |
| yta | Anti Fingerprint, Hard coating (8H) |
| ljusstyrka | 315 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | LVDS (1 ch, 8-bit), 39 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
