| Artikelnummer | LD101WX2-SLP1 |
| varumärke | LG Display |
| Storlek | 10.1 |
| Ansökan | PAD |
| Upplösning | 1280×800 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 500:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LD101WX2-SLP1 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.1 inch |
| upplösning | 1280(RGB)×800 , WXGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| skissera | 229.46×150.2×4.4 mm |
| yta | Antiglare |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193150% |
| respons tid | 35 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| M101NWT4 R3 | IVO | 10.1 | 1024×600 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| EJ070IA-04A | Innolux | 7.0 | 800×1280 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| LTL097QL01-W01 | Samsung | 9.7 | 2048×1536 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
